I developed this activity 3 years ago and I’m actually not sure why I never wrote it up into a How-To science communication blog. Luckily at a recent conference I was asked about this activity a lot and this was enough reason to get it on to paper. Feel free to amend the activity as necessary and to suit your topic and audience.

KIT & PREPARATION:

I used a generic brand of building bricks (because my budget didn’t allow for actual LEGO) and bought two boxes of mixed bricks in a bargain store. First you want to sort the bricks by colour (unless you can buy them by colour). Then you want to decide what shapes to make – I opted for 3 simples shapes: Syncline, Anticline & Oil Reservoir with seal.

A shoe box of leftover LEGO, the 6 models from top, and a tub with the LEGO borehole
The 6 models covered so only the top layer can be seen
A model example each uncovered to show the structures
With the geology built you want to select 3 or 4 areas to make a ‘borehole’ with – I used single bricks but this could be done with the 2×2 squares as well. If you have enough bricks you can probably incorporate the ‘boreholes’ into the model and reveal them by extracting them – which would be super cool. Once you have the models built you need to make some envelopes to only expose the top layer – I used brown packing paper and packing tape to make sure they can be reused easily. That’s pretty much it.

ACTIVITY: Syncline & Anticline

Show your participants the covered models and ask if they can tell you what the rest of it looks like? You can explain that geologists use exposures like this for mapping (having maps on hand can be useful). Also ask how sure they are that they are correct based on the information available. You can then offer more information in form of boreholes – either lay or stand them in front of the model in the correct place (you can mark your envelopes) or extract them if you went for the hiding option.

The exposed model with the ‘boreholes’ in the corresponding place
The hidden models with the ‘boreholes’ in the corresponding place
Either ask the participants to show you what they can see – following a colour for example or ask them to copy the boreholes on a bit of paper and connect colours that way (this will depend on how much time you have with each participant; borehole papers can be prepared with the columns printed on so the participants only have to colour them in). Once that is done reveal the full model. This is normally a big Ahhh effect because just by having that little bit of extra information they got it right. This is a great opportunity to talk about information available and how geologists infer maps and what the subsurface looks like based on similar information. (if you have boreholes logs from the local area + the iGeology app from BGS this can really help relate this to the local area). If you make a version where the boreholes can be retrieved this could be a standalone activity with instructions to follow as well.

ACTIVITY: Oil reservoir with seal

This activity is very similar to the one above except that we can’t see anything from the top layer. And this time we don’t even know where to drill for a borehole. So we have to do a seismic survey. After guessing what the model looks like and deciding the information is not great. Show a generic seismic line (normally easily found online or in petroleum engineering tutorials). We printed seismic lines on A5 and asked participants to colour them in – following any features or structures they could see (this could also be done with one A3 paper that’s laminated and can be re-used). After identifying a generic reservoir structure we revealed the model to show the different layers. A set of boreholes could be done based on where participants would ‘drill’. Which would mean having a set of boreholes available or making the middle of the model retrievable.

A sheet of questions for participants & seismic line in the background
A model example each uncovered to show the structures
SUMMARY: I absolutely love this activity because it uses something people are familiar with – independent of age – and it mimics a little geological survey by taking participants on the journey of gathering information and making an estimation. This activity can also be easily amended for different size audiences (e.g. using DUPLO for a show & tell type event) or adding more information about the process, talking about risk and uncertainty. The response from participants, especially children, when the model is revealed is priceless.

I hope you found this How-to useful and please share how you used it at your events either in the comments or by tagging me (@StephZihms) on Twitter.
